Schneider Electric says its Altivar 312 variable-speed AC drive is designed to make industrial and commercial machines more energy efficient while simplifying its integration into a single control system architecture.



Available in 1-20 hp and up to 600V, the Altivar 312 features high overtorque and the only drive in its class, says the company, with a remote graphic keypad. The 312 comes standard with integrated communication ports for Modbus and CANopen networks, and optional cards for CANopen Daisy Chain, DeviceNet, Profibus DP. Autotuning, multi-loaders and 50 pre-loaded application functions to manage common facility processes simplify setup and installation.



The drive is also fitted with coated cards (IEC 60721-3-3 Classes 3C2 and 3S2) and can withstand temperatures ranging from -10°C to 50°C without derating (even when installed side-by-side). Its integrated EMC (electro-magnetic compatibility) also minimizes power disturbances and electrical interference.







Altistart





Soft start/soft stop unit for infrastructure and industrial applications



Altistart 22 soft start/soft stop unit for 3-phase asynchronous motors



Simplifies installation and operation



Saves time on wiring (6 terminals instead of 12)

Optimises the size of your enclosures (very compact product)

Keeps temperature rises to a minimum (low heat dissipation)

Reduces the number of components to manage (multifunction product)

Protects your installations



Minimises jolts and shocks

Reduces mechanical stresses on the machines

Increases the service life of your installations

Prevents installation failure by detecting and signalling faults such as a blocked motor, underload or incorrect earthing of one of the 3 phases

A safe product with numerous integrated functions



Bypass and safety functions

Protection devices for monitoring the motor, the electrical installation and the starter itself

Simple setup and operation with:

- 4 light emitting diodes (LEDs)

- 4 navigation keys

- 4-digit display

SoMove software for configuring on PC and transferring the configuration via Bluetooth® or using a cable

Coated cards as standard for enhanced resistance to harsh environments
